Bergepanzerwagen IV - Smart Kit
Reviewed by Cookie Sewell
|Stock Number and Description||Dragon Models Limited 1/35 scale ‘39-‘45 Series Kit No. 6438; Sd.Kfz. 164 Bergepanzerwagen IV - Smart Kit|
|Media and Contents:||950 parts (584 in grey styrene, 288 “Magic Track” links, 59 etched brass, 16 clear styrene, 2 copper chain, 1 twisted steel wire)|
|Price:||estimated price about US$50.50|
|Review Type:||First Look|
|Advantages:||First kit of this variant from DML; nicely done jib crane and associated kit|
|Disadvantages:||Still comes with “Magic Track” links|
|Recommendation:||Recommended for all German and Pzkw. IV fans|
It did not take long before – even in WW I – before the countries building and using tanks realized they needed specialized vehicles to recover and repair them. While the Germans initially attempted to use heavy halftracks to carry this task out in WW II, eventually they realized a fully tracked vehicle of the same type was best qualified to do the job. Therefore it was only in October 1944 they began to build dedicated conversion of the Pzkw. IV chassis as tank towing and retriever vehicles – Bergepanzer – to deal with their then standardized medium tank. Only 36 of these vehicles, useful as they were, wound up being converted.
Each came with the basics of the time, mostly focused on being able to tow stuck vehicles or turn over vehicles which had flipped over for one reason or another. For this a winch was mounted in the center of the hull where the turret had previously been fitted. They were also able to pull engines and transmission components for repair or replacement using a manual jib crane which could be dismounted for travel. (For some reason there does not seem to have been any thought – as with American recovery vehicles – to sheave the cable from the winch to the crane boom to power these operations.)
DML has now added a version of this popular conversion subject to their line of Pzkw. IV “Smart Kits” using most of the components from their recent Pzkw. IV Ausf. H Late kit (No. 6300). The turret parts are now mostly removed from the kit and two new sprues with 82 new parts for the Bergepanzer details and the jib crane have been added.
The jib crane is a very neatly detailed assembly and consists of some 29 styrene parts and two lengths of copper chain cut to fit per the directions. There are two different versions of the crane offered so be very attentive when assembling htme as they are difficult to tell apart other than by parts numbers. Note that this is what the Russians call a “trinoga” or three-legged jib and that parts have to be left loose until mounted on the hull.
The kit also provides two different style towing pintles (which they dub “small” and “large” for obvious reasons) and each one takes different fittings.
The majority of the rest of the kit will be familiar to anyone who has built one of the “Smart Kit” Pzkw. IV variants. Drivers now consist of only four parts; the separate bolts are gone. Bogies are now nine piece affairs without separate tires. New details are provided for the tow hook at the rear of the hull as well.
The upper hull again consists of a deck and framework with applique sides, front and rear engine intake components and fenders. The muffler has a central tube section and six add-on parts to complete it along with a “slide molded” exhaust pipe, but note that a new stern plate has to be used for the Bergepanzer variant.
All ports and hatches are separate parts so they can be posed open. While no interior components for the lower hull are yet present, the hull still provides a rudimentary firewall for the engine compartment, and the various vents and louvers are also posable either open or closed. The bow also comes with a well-done machine gun and ball mount. Note that all ports have clear styrene inserts as well.
The kit comes with a large wooden beam and this will take work to make look more like wood. While split lengthwise diagonally to hide the long seams on the edges, the ends will take some sanding and scraping with a razor saw to look like sawn timber and not plastic.
Etched brass is kept to a minimum and only covers items such as the engine air intake louvers, the inner guides of the idler wheels, some small brackets, and the flaps for the engine air intakes on the sides of the rear deck.
Tracks are the “Magic Track” snap-together-then-cement type, and modelers are advised to recall that when facing the head card the left side track links (light grey) are on the left and right (dark grey) are on the right.
Two finishing options are provided along with a small set of Cartograf decals: Unidentified Unit; Germany 1945 (panzer brown overall); Unidentified Unit, Germany 1945 (tricolor upper hull). Alas, the directions do not indicate which is a “small pintle” or “large pintle”.
Technical assistance was provided by Notger Schlegtendal, Tom Cockle and Gary Edmundson.
Overall this is an excellent choice but one which will not go over well with the “after market boys” who have made the conversion kits for this variant.
A 37x2 Pzkw. IV Generic drivers, idlers and return rollers
A 81x2 Pzkw. IV Generic road wheels and bogies
B 17 Brummbaer - front glacis details
B 44 Pzkw. IV Generic turret base and details, gun breech
E 43 Pzkw. IV Ausf. H turret details and applique
G 29 Turret and hull ports, smoke grenade launchers
H 57 Engine deck and details
J 1 Pzkw. IV Ausf. H hull top
J 7 German Generic Jack
J 8 MG-34 machine gun
K 2 Pzkw. IV Ausf. H fenders
K 10 German Generic Antenna and tail light set
L 8 Pzkw. IV spare road wheels
L 144 “Magic Track” left side
M 16 Clear styrene
N 31 Bergepanzer IV derrick crane and fittings
P 33 Pzkw. IV Ausf. H engine grilles and vents
Q 6 Spare track links
R 144 “Magic Track” right side
S 51 Bergepanzer IV upper hull details and kit
X 1 Lower hull pan
Z 1 Twisted metal wire
MA 59 Etched brass
A 1 220mm large link copper chain
B 1 285mm small link copper chain
Thanks to Freddie Leung for the review sample.
